ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER.
SPECIFICATION:
- Wingspan: 2600 mm
- Length: 2230 mm
- Weight: 15 kg
- Wing area: 177 dm2
- Wing loading: 128.2 g/dm2
- Wing type: Naca Airfoil
- Servo mount: 42mm x 21mm
- Gear type: Air retract gear with oleo struts for main gear and air retract gear with oleo struts for tail gear (included).
Parts listing required (not included):
- Radio: 7 channels
- Servo: 9 standard high torque servos
- Engine: 120 cc gas
- EP Motor: Brushless outrunner 185 KV
- Propeller Electric Motor: 28 x 10
- Propeller Gas Engine: 27 x 10
Recommended motor and battery set up (not included):
- Electric Motor: BOOST 180
- Battery: 12S LIPO 44.4V 6000mAh
- Speed control: High Voltage 120A
- Receiver battery: 6.0V 2400-2600mAh (2 Packs)
- Torque servos: 11.3kg/cm – 12.9kg/cm
